rock bit rubber sealed rolling bearing bits
Product Detail
Model No.:
3 1/2~ 18 1/2in/65mm-660
Production Capacity:
500 pieces/month
Delivery Date:
7-10 days
Style:
Others
colour:
blue or as your requirement
formation:
strength,soft formation
inches:
3-26inches
Means of Transport:
Ocean,Land,Air
Packing:
wooden case
Type:
Utility
Brand Name:
HY,HuanYu, KingDream,JZ,LiL...
certificate:
ISO9001&API
IADC:
114-117,127,437,517,617,637
port:
tianjin
1Certified by ISO9001&API
2Used for water well, oil field
3IADC:114-117,127,437,517,617,637
4.type:rolling bearing journal
5.delivery on tim
Hejian HuanyuPetroleum Machinery Co., Ltd. was founded in 1998, located in the center of North China and Beijing open highway, Cang Shi Highway, the road adjacent to Beijing and Tianjin Shi, Beijing-Kowloon railway, Beijing-o-rail from the left and right after. South of the capital170 km, 110 km to Tianjin, North China Pearl Baiyangdian 35 km, excellent location and convenient transportation, a favorable convenient conditions for our development.We mainly specializes in Tricone Bits. TCI Rock Bits,Steel Tooth Tricone Bits,PDC Bits, PDC Drag Bits, PDC Core Bits, Single Bits, Bits Cones for oil,water and mining drilling.The material all tungsten carbide or high carbon steel, And the quality in accord with API and ISO standards.
TCI tricone bits for Mining and Rock Drilling
The strength and wear resistance of inserts are improve by using carbide inserts with high strength
and high wear resistance.
Surface of the high precision bearing heat treated by using advanced heat treatment process to improve the load capacity and service life of the bearing.
The service life of the bearing is further extended by adopting harder and mort wear resistant material for thrust bearing.
Preventing reflux structure has dual function, it can avoid air counterflow and dust entering into bearing when the air-compressor stop working accidentally, and separate air and water in order to avoid water entering into bearing when it works normally to prolong the life of bearing.
TCI tricone bits for Oil Drilling
Inserted tricon bits
1. This series tricone bit use Sealed roller bearing structure. With rollers arranged in grooves recessed in the cone body, the size of the bearing journal is increased.
2. Thrust bearing surfaces are hardfaced and treated with friction reducing technology.
3. Ball locked cone, suitable for high rotary speed.
TCI Tricone bits
1 This series tricone bit use Journal bearing. Hardfaced head bearing surface. Cone bearing inlaid with friction reducing alloy and then silver-plated. The load capacity and seizure resistance of the bearing is greatly improved.
2. O ring seal is made of the more wear resistance high saturated buna-N with the increased seal section and precisely designed sealing flange in the cone sealing area increased the reliability of the seal.
3. The bit bearing can be ball locked
4. For steel tooth bit, the tooth surface is hardfaced with new type of wear resistan
Material and thus extended working life of the cutting structure while still maintaining high ROP. 5..Main Availability
Hejian Huanyu Petroleum Machinery Co., Ltd. |
Product | Size | IADC CODE |
TCI Tricone Bit | 3 7/8 ,5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, 22, 24,26 | 417 427 437 517 527 537 617 637 737 |
Steel Tooth Tricone Bit | 3 7/8 ,5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, 22, 24,26 | 115 116 117 215 216 217 315 316 317 325 327 |
(3 blades-9 blades) | 5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, | M223,M322,M316, M222,M416,M122 |
we also can supply reamer bits, if you need we always at service for you.
