small size tricone bits from China manufacturer - Hejian Huanyu Petroleum Machinery Co., Ltd.

Price:	205.0~10000.0 USD
Payment Terms:	T/T,L/C,D/A
Special Groups:	TCI tricone bits (153)
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: IADC114

Production Capacity: 150 per week

Delivery Date: 7-10 days

color: blue and golden or accordin...

package: fumigation wooden box

sealed material: rubber sealed and metal sea...

certification: API and ISO9001

Means of Transport: Ocean

Packing: wooden case

Brand Name: HY,HuanYu, KingDream,JZ,LiL...

material: steel and tugsten carbide

export experience: many years experience

bearing type: sealed and non-sealed

port: Tianjin port or Beijing por...

1Certified by ISO9001&API
2Used for water well, oil field
3IADC:114-117,127,437,517,617,637
4.type:rubber sealed metal
5.delivery on time

Tricone bit, steel tooth bit, TCI bit, single cone bit,tricone bits,rotary bits

1. Cutting Structure of this series tricone rock bit :
The durability of premium tungsten carbide inserts is improved with new formulas and new techniques for insert bit.The wear-resistance of teeth is enhanced with premium tungsten carbide hardfacing on the tooth surfaces for steel tooth bit.

2. Gauge Structure of this series tricone rock bit :
Multiple gauge protection with gauge trimmers on heel and gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.

3.Bearing Structure of this series tricone rock bit :
High precision bearing with two thrust faces. Balls lock the cone.Hardface heard bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver-plated. Abrasion resistance and seizure resistance of the bearing are improved and suitable for high rotary speed.

4.Seal and Lubrication of this series tricone rock bit :
The advanced metal seal package consists of two metal seats and two elastic energizers. Compressed energizers ensure good contact being kept on two sealing surfaces of metal rings by elastic force, and achieve the bearing seal. In the drilling, metal seal are relatively dynamic, and the energizers are static. This will improve the reliability and durability of bearing seal. The pressure compensator system and advanced grease can greatly increase the lubricating reliability.

5.Product Application of this series tricone rock bit :
It is suitable for downhole motor and high speed applications.

6.Main Availability

Size			Bit Type
In.	mm
6	152.4	4.7,517, 537, 617, 637
6 1/2	165.1	437,517,537,617,637
7 1/2	190.5	517, 537
8 1/2	215.9	437, 535,517, 537,617,637
9 1/2	241.3	437, 517,537,617,637
9 5/8	244.5	517,535,537
9 7/8	250.8	517,537
12 1/4	311.1	437, 517,535, 537,617,637
17 1/2	444.5	517,535,537
