small size 3inch to 6inch tricone drill bits from China manufacturer - Hejian Huanyu Petroleum Machinery Co., Ltd.

small size 3inch to 6inch tricone drill bits

Price:	250.0~10000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU,
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 17 1/2 437 517 617 627 737

Production Capacity: 500 pieces/month

Delivery Date: 7-10 days

Style: Others

colour: blue or as your requirement

formation: strength,soft formation

export experience: 5 years

Means of Transport: Ocean,Land,Air,

Packing: wooden case

Type: Utility

Brand Name: HY,HuanYu, KingDream,JZ,LiL...

certificate: ISO9001&API

IADC: 114-117,127,437,517,617,637

port: tianjin

1Certified by ISO9001&API
2Used for water well, oil field
3IADC:114-117,127,437,517,617,637
4.type:sealed and non sealed
5.delivery on time

Main structure

1.STEEL TOOTH bits for Mining and Rock Drilling
The strength and wear resistance of inserts are improve by using carbide inserts with high strength

and high wear resistance.
Surface of the high precision bearing heat treated by using advanced heat treatment process to improve the load capacity and service life of the bearing.
The service life of the bearing is further extended by adopting harder and mort wear resistant material for thrust bearing.
Preventing reflux structure has dual function, it can avoid air counterflow and dust entering into bearing when the air-compressor stop working accidentally, and separate air and water in order to avoid water entering into bearing when it works normally to prolong the life of bearing.
2. STEEL TOOTH bits for Oil Drilling
Inserted tricon bits
1. This series tricone bit use Sealed roller bearing structure. With rollers arranged in grooves recessed in the cone body, the size of the bearing journal is increased.
2. Thrust bearing surfaces are hardfaced and treated with friction reducing technology.
3. Ball locked cone, suitable for high rotary speed.
3.Steel teeth Tricon bits
1 This series tricone bit use Journal bearing. Hardfaced head bearing surface. Cone bearing inlaid with friction reducing alloy and then silver-plated. The load capacity and seizure resistance of the bearing is greatly improved.
2. O ring seal is made of the more wear resistance high saturated buna-N with the increased seal section and precisely designed sealing flange in the cone sealing area increased the reliability of the seal.
3. The bit bearing can be ball locked
4. For steel tooth bit, the tooth surface is hardfaced with new type of wear resistan
Material and thus extended working life of the cutting structure while still maintaining high ROP. 5..Main Availability

Hejian Huanyu Petroleum Machinery Co., Ltd.
Product	Size	IADC CODE
TCI Tricone Bit	3 7/8 ,5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, 22, 24,26	417 427 437 517 527 537 617 637 737
Steel Tooth Tricone Bit	3 7/8 ,5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, 22, 24,26	115 116 117 215 216 217 315 316 317 325 327
PDC BIT (3 blades,4 blades, 5 blades,6 blades)	5 1/2, 6 1/2 7 7/8,8 1/2,8 3/4 10 5/8,12 1/4 13 3/4, 17 1/2, 22, 24,26	M223,M322,M316, M222,M416,M122
