yellow Steel Tooth Tricone Bit from China manufacturer - Hejian Huanyu Petroleum Machinery Co., Ltd.

Price:	800.0~10000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU,
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 437 517 617 627 737 537

Production Capacity: 1000 pieces/month

Delivery Date: within 7 days

Style: Others

certificate: ISO9001&API

IADC: 114-117,127,437,517,617,637

port: tianjin

Market: all the world

Means of Transport: Ocean,Land,Air,

Packing: wooden box, steel box or as...

Type: Utility

Size: 3

bearing: sealed or rock bearing

color: blue or yellow

Payment Terms: T/T and L/C

use: water and oil well drilling

1. API&ISO 9001
2.Size: 95.3mm-660.4mm
3.high quality and best price
4.covers all IADC codes
5.more inventory

TCI tricone bit,button bit,drill cone bit,tricone bit,TCI tricone rock bit

1.Cutting Structure

The durability of premium tungsten carbide inserts is improved with new formulas and new techniques for insert bit.

2.Gauge Structure

Multiple gauge protection with gauge trimmers on heel and gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.

3.Bearing Structure

High precision bearing with two thrust faces. Balls lock the cone.Hardface heard bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver-plated. Abrasion resistance and seizure resistance of the bearing are improved and suitable for high rotary speed.

4.Seal and Lubrication

The advanced metal seal package consists of two metal seats and two elastic energizers. Compressed energizers ensure good contact being kept on two sealing surfaces of metal rings by elastic force, and achieve the bearing seal. In the drilling, metal seal are relatively dynamic, and the energizers are static. This will improve the reliability and durability of bearing seal. The pressure compensator system and advanced grease can greatly increase the lubricating reliability.

Size		Bit Type
In.	mm	Bit Type
6	152.4	517, 537, 617, 637
6 1/2	165.1	617
7 1/2	190.5	517, 537
8 1/2	215.9	437, 517, 537,617,637
9 1/2	241.3	437, 517,537,617,637
9 5/8	244.5	517,537
9 7/8	250.8	517,537
12 1/4	311.1	437, 517, 537,617,637
17 1/2	444.5	517,537

Huanyu is registered with 3 million RMB capital, possesses over 180mu area and 70 various manufacturing equipment.Our company has 290 employees, including three professors, 12 senior engineers and 37 intermediate technicians. Advanced technology and equipment, excellent technicians, and scientific management will guarantee our products have superior quality, highly competitive prices and speedy delivery.Huanyu products not only won the trust of domestic clients, but also are exported to USA,Middle East,South Africa, etc. .
