8 3/4 tricone drilling bits
Price: |
250.0~10000.0 USD |
Payment Terms: |
T/T,L/C,D/A,D/P,WU, |
Special Groups: |
TCI tricone bits (153)
|
Place of Origin: |
Hebei, China (Mainland) |
Product Detail
Model No.:
HY317,417 8 3/4''
Production Capacity:
500 pieces/month
Delivery Date:
7-10 days
Style:
Others
colour:
blue or as your requirement
formation:
strength,soft formation
blades:
3-8blaeds
Means of Transport:
Ocean,Land,Air,
Packing:
wooden case
Type:
Utility
Brand Name:
HY,HuanYu, KingDream,JZ,LiL...
certificate:
ISO9001&API
IADC:
114-117,127,437,517,617,637
port:
tianjin
1Certified by ISO9001&API
2Used for water well, oil field
3IADC:114-117,127,437,517,617,637
4.type:3-8blades
5.delivery on time
Specifications
TCI tricone bit
1.size range from 3 7/8" to 26"
2.Covers almost all IADC code.
3.Meet with API Spec7-1 Standard
1.Cutting Structure
The durability of premium tungsten carbide inserts is improved with new formulas and new techniques for insert bit.
2.Gauge Structure
Multiple gauge protection with gauge trimmers on heel and gauge inserts on the gauge surface of the cone,
tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
3.Bearing Structure
High precision bearing with two thrust faces. Balls lock the cone.Hardface heard bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver-plated. Abrasion resistance and seizure resistance of the bearing are improved and suitable for high rotary speed.
4.Seal and Lubrication
The advanced metal seal package consists of two metal seats and two elastic energizers. Compressed energizers ensure good contact being kept on two sealing surfaces of metal rings by elastic force, and achieve the bearing seal. In the drilling, metal seal are relatively dynamic, and the energizers are static. This will improve the reliability and durability of bearing seal. The pressure compensator system and advanced grease can greatly increase the lubricating reliability.
Size | Bit Type |
In. | mm |
6 | 152.4 | 517, 537, 617, 637 |
6 1/2 | 165.1 | 617 |
7 1/2 | 190.5 | 517, 537 |
8 1/2 | 215.9 | 437, 517, 537,617,637 |
9 1/2 | 241.3 | 437, 517,537,617,637 |
9 5/8 | 244.5 | 517,537 |
9 7/8 | 250.8 | 517,537 |
12 1/4 | 311.1 | 437, 517, 537,617,637 |
17 1/2 | 444.5 | 517,537 |
