good quality PDC drilling bit

Price: 250.0~10000.0 USD
Payment Terms: T/T,L/C,D/A,D/P,WU
Special Groups: PDC matrix/ steel body bit (48)
Place of Origin: Hebei, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: 3 wings-8wings
Production Capacity: 500 pieces/month
Delivery Date: 7-10 days
Style: Others
colour: blue or as your requirement
Size: 6'-17 1/2'
Formation: soft to hard formation
Advantage: high quality on time delive...
Means of Transport: Ocean,Land,Air
Packing: wooden case
Type: Utility
Brand Name: HY,HuanYu, KingDream,JZ,LiL...
Material: ally steel, tungsten carbi...
Certification: API
Payment term: L/C at sight,T/T
Bearing sealed: metal sealed(HJ) rubber se...

1.Competitive Price(larger order, lower price)
2.Perfect Quality Control System
3.Excellent Sevice
4.Large Business scale

---14 years experience in drill bits industry
---exported to more than 20 countries
---competitive price with good quality
---brands available: Huanyu, Kingdream/JZ, CS, Lilin, BEST, Chuanke
---fast delivery
---you run at no risk here
The minimum order: 1/pc
Payment: T/T, 30% as deposit, the balance 70% paid before shipment
Delivery Time: 5 days after payment received,
Volume: about USD80/RT
To Dubai port the shipping: take 45-48days
Any question, ask me freely.
Hejian HuanyuPetroleum Machinery Co., Ltd. was founded in 1998, located in the center of North China and Beijing open highway, Cang Shi Highway, the road adjacent to Beijing and Tianjin Shi, Beijing-Kowloon railway, Beijing-o-rail from the left and right after. South of the capital170 km, 110 km to Tianjin, North China Pearl Baiyangdian 35 km, excellent location and convenient transportation, a favorable convenient conditions for our development.We mainly specializes in Tricone Bits. TCI Rock Bits,Steel Tooth Tricone Bits,PDC Bits, PDC Drag Bits, PDC Core Bits, Single Bits, Bits Cones for oil,water and mining drilling.The material all tungsten carbide or high carbon steel, And the quality in accord with API and ISO standards.
TCI tricone bits for Mining and Rock Drilling
The strength and wear resistance of inserts are improve by using carbide inserts with high strength
and high wear resistance.
Surface of the high precision bearing heat treated by using advanced heat treatment process to improve the load capacity and service life of the bearing.
The service life of the bearing is further extended by adopting harder and mort wear resistant material for thrust bearing.
Preventing reflux structure has dual function, it can avoid air counterflow and dust entering into bearing when the air-compressor stop working accidentally, and separate air and water in order to avoid water entering into bearing when it works normally to prolong the life of bearing
.
TCI tricone bits for Oil Drilling
Inserted tricon bits
1. This series tricone bit use Sealed roller bearing structure. With rollers arranged in grooves recessed in the cone body, the size of the bearing journal is increased.
2. Thrust bearing surfaces are hardfaced and treated with friction reducing technology.
3. Ball locked cone, suitable for high rotary speed.
TCI Tricone bits
1 This series tricone bit use Journal bearing. Hardfaced head bearing surface. Cone bearing inlaid with friction reducing alloy and then silver-plated. The load capacity and seizure resistance of the bearing is greatly improved.
2. O ring seal is made of the more wear resistance high saturated buna-N with the increased seal section and precisely designed sealing flange in the cone sealing area increased the reliability of the seal.
3. The bit bearing can be ball locked
4. For steel tooth bit, the tooth surface is hardfaced with new type of wear resistan
Material and thus extended working life of the cutting structure while still maintaining high ROP. 5..Main Availability
Hejian Huanyu Petroleum Machinery Co., Ltd.
Product
Size
IADC CODE
TCI Tricone Bit
3 7/8 ,5 1/2, 6 1/2
7 7/8,8 1/2,8 3/4
10 5/8,12 1/4
13 3/4, 17 1/2,
22, 24,26
417 427 437
517 527 537
617 637 737
Steel Tooth Tricone Bit
3 7/8 ,5 1/2, 6 1/2
7 7/8,8 1/2,8 3/4
10 5/8,12 1/4
13 3/4, 17 1/2,
22, 24,26
115 116 117 215 216
217 315 316 317 325 327
(3 blades-9 blades)
5 1/2, 6 1/2
7 7/8,8 1/2,8 3/4
10 5/8,12 1/4
13 3/4, 17 1/2,
M223,M322,M316,
M222,M416,M122
The IADC code introduction of TCI tricone bits
tricone bit Cutting structure: very long widely spaced ,chisel-shaped inserts and considerable cone axis offset against center line of bit ensure very high penetration rate .To secure the bit from diameter loss, the gage protection inserts have got shorter length and greater angle of the top. Formations: long intervals of very soft poorly compacted shales ,sandstone, clays, salts and soft li mestones. Size and IADC available: 3 3/4" to 26" IADC 415,435,445,417,437,517,537,617
TCI 437 soft formation tci tricone bits
The 437 tci bits are used to drill low compressive strength very soft formation tci bits maximize the use of bothconical and chisel tungsten carbide inserts of large diameters and high projection. This cutting structure design combined with maximum cone offset ,results in high bit penetration rates.the deep intermesh of cutter rows prevents bit bailing in sticky formations.
TCI 517   medium formation tci tricone bits
The 517 features aggressive chisel tungsten carbide inserts on the heel rows and inner rows this design provides a fast drilling rate and added cutting structure durability in medium to medium hard for mations the HSN rubber o-ring provides adequate sealing for bearing durability.
TCI 637 can be used to drill hard and abrasive forma-tions .wear –resistant tungsten carbide inserts are used in the outer rows to prevent loss of bit gauge.maximum numbers of hemispherical-shaped inserts are used in all rows to provide cutter durability and long life.
TCI 617 the tci 617 features robust chisel tungsten carbide inserts on the heel row and conical on the inner rows .this design provides a fast drilling rate and added cutting structure durability in medium to medium hard formations . the HSN rubber o-rin provides adequate sealing for bearing durability .
Steel tooth bit
Tricone Steel Tooth Bits
1) Product description
1. Elastomer (Rubber) Sealed Roller Bearing Bit
Cutting Structure
The wear-resistance of teeth is enhanced with premium tungsten carbide hardfacing on the tooth surfaces for steel tooth bit.
Gauge Structure
Multiple gauge protection with gauge trimmers on the heel and gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
Sealed Bearing Structure
1.Abrasion resistance and seizure resistance of the bearing are improved.
2.Premium O-ring, Optimal seal compression and curved seal structure can enhance the seal performance.
Main Type Available
Size: 5 7/8",6",6 1/2",7 1/2", 7 7/8",8 1/2",9 1/2", 9 5/8",9 7/8",12 1/4",13 5/8",14 3/4",15",15 1/2",17 1/2",22",24",26", etc.
IADC Code:1-- Series, 2-- Series,3-- Series
2. Air Cooling Roller Bearing Steel Tooth Bit
Cutting Structure
The wear-resistance of teeth is enhanced with premium tungsten carbide hardfacing on the tooth surfaces for steel tooth bit.
Gauge Structure
Gauge protection with gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability.
Sealed Bearing Structure
Air cooling roller bearing package. Balls lock the cone which reduces the probability of cone-dropping to minimum.
Main Type Available
Size:5 7/8",6",6 1/2",7 1/2", 7 7/8",8 1/2",9 1/2", 9 5/8",9 7/8",12 1/4",14 3/4",17 1/2", etc.
IADC Code:1-- Series, 2-- Series, 3-- Series
3. Non-Sealed Roller Bearing Steel Tooth Bit
Cutting Structure
The wear-resistance of teeth is enhanced with premium tungsten carbide hardfacing on the tooth surfaces.
Sealed Bearing Structure
Non-sealed roller bearing. Drilling fluid can enter the bearing directly for cooling; Balls lock the cone which reduces the probability of cone Cdropping to minimum.
Main Type Available
Size: 2 3/8",3",3 5/8:",3 7/8",4",4 1/2",4 5/8",4 3/4",6",6 1/2",7 1/2", 7 7/8",8 1/2",9 1/2", 9 5/8",9 7/8",10 5/8",12 1/4", 17 1/2",etc.
IADC Code:1-- Series,2-- Series,3--
The 114-117soft formation tooth bits are used to drill low-compressive strength ,soft formations long projection tooth lengths are used on high offset cones to provide the greatest penetration rates possible. Wear-resistent hard facing is used to control tooth wear. On the softest bit types this hard facing completely covers the bit teeth.
The 127 medium – hard formation tooth bits
Used to drill high-compressive strength medium hard formations   short projection teeth with reduced crest length are used in this series of bit designs durable hard facing is applied to reduce tooth wear.
Milled tooth bit specializes in designing, manufacturing, marketing and serving the high performance diamond bits and drilling tools used in petroleum industry .The company is established by the top experts of the field ,and equipped with advanced equipments and facilities .Our diamond bits named Great, which ranging from 3"to 17-1/2".All the products have been awarded the ISO9001 certificate.Furthermore, the experienced and knowledgeable service team will ensure all the superior performance of our products in both the domestic and international market.With our service pursuit "Drilling requirement initially ,Customer satisfaction finally ",we assure the products the best quality by adopting advanced design technology ,manufacturing process and strict quality control .Our company will always improve and innovate to satisfy different needs for all users in the entire world
Paymeny Terms:
30% payment advanced, then 70% payment before shipping.
Shipping Terms:
By Sea/By Air Or As Your Requirements
We also can other types and sizes drilling tools
PLs add this formation in your inquiry.
1) the size of the tricone bit
2) the IADC tooth model, like 537G
3) PLs tell the drilling information of the layer.
4) PLs tell the quantity.
